Vysílačka KG-UVD2P pásmo 136-174MHz, 400-480 MHz - Wouxun

•  CE FCC approved.(FCC ID:WVTWOUXUN04)

• Frequency Range Can Be Suitable For Different Countries or Areas
 136-174&400-480 MHz (RX/TX)


 FM: 76-108 MHz(RX)
 • Work Mode:U-V?U-V?V-V?U-U can be set freely
 • SOS Function
 • 1750Hz tone
 • DTMF Encoding Function
 • CTCSS/DCS Scan(Digital/Analog)
 • Bright Flashlight Illumination
 • Band Can Be Set Freely on The Same Channel VHF TX-UHF RX or UHF TX-VHF RX
 • English Voice Guide
 • Digital FM Radio
 • Wide/Narrow Bandwidth Selection(25khz/12.5khz)
 • Priority Scan, Add Scanning Channel
 • High/Low Power Selection
 • Channel Name Edit and Display
 • 50 Groups CTSS/105Groups DCS
 • Multi Step Frequency:(5K/6.25K/10K/25K/50K/100K)
 • Multi Scan
 • VOX Transmission
 • Transmit Overtime Voice Prompt
 • Begin/End Transmitting BEEP Prompt
 • Auto/Manual Keypad Lock
 • Wire Clone, Programmable By Computer
 • Stopwatch Function
 • Lowe Voltage VOICE prompt
 • Busy Channel Lockout

  Technical Specification:

 KG-UVD2P Technical Specification
 Frequency Range  Frequency Range Can Be Suitable For Different Countries or Areas
  136-174&400-480 MHz (RX/TX)
  FM: 76-108 MHz(RX)

 Memory Channels
 128 channels

 Frequency Stability
 ±2.5ppm

 Operating Voltage
 7.4V

 Operating Temperature
  -30?~+60?
Waterproof IP 55

 Antenna Impedance
 50?

 Dimension
 58×105×38(mm)

 Weight
 250g

 Transmitter

 Frequency Stability
 ±2.5PPM

 RF Carrier Power
 UHF: 4W VHF: 5W

 Effective Radiation Power (ERP)
 within pre-determined value ±7.5dB

 Max. Frequency Deviation
 Channel Space: 25KHz  ±5KHz

 Channel Space: 12.5KHz ±2.5KHz

 Audio Modulation
 +3dB (pre-emphasis by 6dB between 0.3-3KHz)

 Adjacent Channel Power
 Channel Space: 25KHz  ?70 dB

 Channel Space: 12.5KHz  ?60 dB

 Spurious Radiation
 ?-30dBm

 Inter modulation Attenuation
 ?40dB

 Modulation Distortion
 ?10%

 Residual FM
 ?-35dB

 Residual AM
 ?3%

 Receiver

 Sensitivity (12dB SINAD)
 0.16µV

 Squelch Rejection Sensitivity
 ?0.8µV

 Squelch Sensitivity
 ?0.2µV

 Audio Output power
 500mW

 Audio Distortion
 ?5%

 Audio Response
 (300-3000Hz)  +1 to -3dB

 Co-channel Rejection
 ?-8.0dB

 Performance of Amplitude Limiter
 ?3

 Adjacent Channel Selection
 Channel Space: 25KHz  ?70 dB

 Channel Space: 12.5KHz  ?60 dB

 Inter-modulation
 ?65 dB

 Resistance
 ?84 dB

 Spurious Radiation
 9KHz-1GHz?-57dBm

 1GHz-4GHz?-47dBm
